Description

Applications of the Dusty Evo Vacuum

Because of its high-performance design, the Dusty Evo is best suited for low to medium levels of smoke and dust generated during welding, soldering, or cutting processes. It offers dependable performance for occasional use in workshops, garages, and repair facilities, while remaining highly effective when paired with extraction nozzles, funnels, and torches.

Key Benefits of the Dusty Evo Smoke Extraction Unit

The Dusty Evo delivers numerous benefits to businesses and individual users including:

• High Extraction Capacity: Two powerful turbines deliver consistent suction performance, even during demanding welding and cutting tasks.
• Cleanable Filter: It includes manual filter cleaning with a cleaning indicator, so operators know exactly when maintenance is required.
• Worker Health Protection: KemTex® ePTFE filter cartridges capture fine hazardous particles through surface filtration and meet safety standards recognized across North America.
• Regulatory Compliance: By removing harmful fumes, the Dusty Evo helps businesses stay aligned with occupational health and safety regulations such as OSHA and CSA requirements.
• Lightweight and Portable: Its compact design, rigid handle, and recessed grips make it easy to move between confined spaces, workshops, and construction sites.
• Adaptable Performance: Stepless speed control allows operators to adjust suction power to the specific welding process, helping reduce energy use when full capacity is not required.

Technical Data

Filter Details

Filter Stages	1
Filter Method	Cleanable Filter
Filter Cleaning Method	Manual
Filter Surface	153 CFM (1.35 m²)
Type of Filter	Filter Cartridge
Filter Material	ePTFE Membrane
Filter Efficiency	> 99.9%
Dust Classification	M

Basic Product Data

Extraction Capacity	153 CFM (260 m³/h)
Fan Performance	200 CFM (340 m³/h)
Dimensions (W x T x H)	16.1″ x 18.6″ x 39.5″ (410 x 472 x 1004 mm)
Weight	65.0 lbs (29.5 kg)
Motor Power	1.7 kW
Power Supply	1 x 230 V / 60 Hz
Rated Current	8.7 A
Noise Level	74 dB(A)

Additional Features

Fan Type	Suction Turbine
Hose Connection	Ø1.77″ / Ø2.48″ (Ø45 mm / Ø63 mm)
Dust Collection Tray	6 l

Why Choose the Dusty Evo High Vacuum Filter System

The Dusty Evo is designed to deliver value for both businesses and independent professionals by combining health protection, regulatory compliance, and ease of use in one compact system.

By protecting employee health, the unit helps lower absenteeism, minimize long-term health risks, and reduce related costs. A cleaner, safer environment also contributes to higher productivity and greater employee satisfaction.

For independent tradespeople and small workshops, it offers a portable, affordable solution that is simple to use and maintain.

Dusty Evo Spec Sheets

For more information about the Dusty Evo vacuum smoke extraction filter unit, please download our product spec sheets below:

• Datasheet
• Operating Instructions
• Overview Dusty Evo

Available Product Accessories

• Automatic Start-Stop for Energy Savings
• Tool Tray with Cup Holder for Added Convenience on Site
• Suction Hose
• Slot Nozzle for Targeted Fume Extraction
• Funnel Nozzle for Wider Coverage
• Connector for Welding Torches
